Machine vision in focus
| Sensor | GMAX3405 |
| Image Sensor | 2/3″CMOS |
| Shutter | Global |
| Resolution | 2448 x 2048 |
| Frame Rate | 118 fps |
| Bit Depth | 10 |
| Mono/Color | Mono |
| Pixel Size | 3.4 ?m x 3.4 ?m |
| Pixel | 5 MP |
| S/N Ratio | 39 dB |
| Image Format | Mono8/10/12 |
| Binning | Support |
| ROI | Support |
| X Flip | Support |
| Y Flip | Support |
| Gain | Analog gain: 1x ~ 2x, Digital gain: 1x ~ 32x |
| Gamma | From 0 to 4, support LUT |
| Exposure Time | 1 ?s?15 s |
| Trigger Mode | Software Trigger/Hardware Trigger/Free Run Mode |
| SPC | Support |
| user Setting | Support two sets of user-defined configurations |
| Port | CXP-6 |
| GPIO Interface | 1x Opto-isolated input, 1x Opto-isolated output, 1x configurable input and output |
| Lens Mount | C-mount |
| Power Supply | DC 24V power supply via 6 Hirose interface?support PoCXP |
| Power Consumption | 5.2 W |
| Product Dimensions | 60 mm x 60 mm x 40 mm (not including rear case connector) |
| Net Weight | 224 g |
| Storage Temperature | -30??+80? |
| Operating Temperature | 0??+40? |
| Binning | Support |
|---|---|
| Bit depth | 10 |
| Exposure time | 1 us~15 s |
| Frame rate | 118 fps |
| Gain | Analog gain: 1x ~ 2x, Digital gain: 1x ~ 32x |
| Gamma | From 0 to 4, support LUT |
| Gpio interface | 1x Opto-isolated input, 1x Opto-isolated output, 1x configurable input and output |
| Image format | Mono8/10/12 |
| Image sensor | 2/3"CMOS |
| Lens mount | C-mount |
| Pixel | 5 MP |
| Pixel size | 3.4 um x 3.4 um |
| Port | CXP-6 |
| Power consumption | 5.2 W |
| Power supply | DC 24V power supply via 6 Hirose interface，support PoCXP |
| Resolution | 2448 x 2048 |
| Roi | Support |
| Sensor | GMAX3405 |
| Shutter | Global |
| Spc | Support |
| Storage temperature | -30℃~+80℃ |
| Trigger mode | Software Trigger/Hardware Trigger/Free Run Mode |
| User setting | Support two sets of user-defined configurations |
| X flip | Support |
| Y flip | Support |
| Mono-color | Mono |
| S/n ratio | 39 dB |
