A3504CG000E

Sensor	AR0521
Image Sensor	1/2.5″CMOS
Shutter	Rolling
Resolution	2592 × 1944
Frame Rate	23 fps
Bit Depth	12
Mono/Color	Color
Pixel Size	2.2 μm × 2.2 μm
Pixel	5.0 MP
S/N Ratio	40 dB
Dynamic Range	74.3 dB
Image Format	Mono8,BayerRG8/10/10Packed/12/12Packed,YUV422_8_UYVY,YUV422_8
ROI	Support
X Flip	Support
Y Flip	Support
Gain	1～32
White Balance	Support
Gamma	From 0 to 4, support LUT
Exposure Time	21.5 μs～1 s
Trigger Mode	Software Trigger/Hardware Trigger/Free Run Mode
SPC	Support
User Setting	Support two sets of user-defined configurations
Image Buffer	256 MB
Port	GigE, PoE
GPIO Interface	1× 6 pin Hirose: 1× Opto-isolated input, 1× Opto-isolated output, 1 configurable input and output
Lens Mount	C-mount
Power Supply	PoE/ DC 9V~24V power supply via Hirose interface
Power Consumption	12 V≈2.8 W
Product Dimensions	29 mm × 29 mm × 42 mm (not including lens mount and rear case connector)
Net Weight	88 g
Storage Temperature	-30℃~+80℃
Operating Temperature	0℃~+50℃

Description

Gigabit Ethernet interface, providing 1Gbps bandwidth with a maximum transmission distance of 100m
128MB on-board cache for data transmission or image resend
Support Software Trigger/Hardware Trigger/Free Run Mode
Support ISP functions including Sharpness/Denoising/Gamma/LUT/BlackLevel Correction/TargetBrightness/Contrast etc.
Support multiple image data formats output/ROI/Binning/Mirror, etc.
Conform to GigE Vision V2.0 protocol and GenICam standard
Conform to CE, FCC, UL, RoHS

Bit depth	12
Dynamic range	74.3 dB
Exposure time	21.5 us~1 s
Frame rate	23 fps
Gain	1~32
Gamma	From 0 to 4, support LUT
Gpio interface	1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Image buffer	256 MB
Image format	Mono8,BayerRG8/10/10Packed/12/12Packed,YUV422_8_UYVY,YUV422_8
Image sensor	1/2.5"CMOS
Lens mount	C-mount
Pixel	5.0 MP
Pixel size	2.2 um x 2.2 um
Port	GigE, PoE
Power consumption	12 V≈2.8 W
Power supply	PoE/ DC 9V~24V power supply via Hirose interface
Resolution	2592 x 1944
Roi	Support
Sensor	AR0521
Shutter	Rolling
Spc	Support
Storage temperature	-30℃~+80℃
Trigger mode	Software Trigger/Hardware Trigger/Free Run Mode
User setting	Support two sets of user-defined configurations
White balance	Support
Mono-color	Color
S/n ratio	40 dB
X flip	Support
Y flip	Support
